What Is a Pit-Type Weighbridge?

A pit-type weighbridge is a heavy-duty weighing platform installed flush with the ground. It sits within a recessed pit, eliminating the need for ramps and offering a seamless vehicle entry and exit.

Benefits of Pit-Type Design

• Space-efficient — No ramps means minimal footprint.

• Seamless vehicle movement — Flush design ensures smooth entry/exit.

• Protected components — Load cells and electronics are housed beneath ground level, offering better environmental protection and aesthetics.

Typical Specifications for a 60-Ton Pit-Type Weighbridge

While I couldn’t locate a SIYOL‑specific spec sheet, here’s what a similar 60‑ton analog pit‑type weighbridge would usually include:

1. Capacity & Accuracy

• Max Capacity: 60 metric tons (60,000 kg)

• Accuracy Division: Often in the range of 10 kg or 20 kg for analog systems

2. Platform Dimensions

• Typical Width: ~3 meters

• Length Options: 9 m, 12 m, 15 m, 18 m—depending on configuration

3. Construction & Materials

• Fabricated using U‑beam or I‑beam steel structures with transverse reinforcements.

• Platform tops are finished with mild steel checkered or smooth plates, often anti‑corrosion treated.

4. Load Cells & Protection

• Fully sealed stainless‑steel load cells, rated IP68 or IP69K (suitable for harsh/dusty environments).

• Overload Protection: 150–200% of full scale (typical)

5. Electronics & Display

• Analog weighbridges use mechanical dial indicators or robust LED/LCD panels.

• Optional features: onboard data storage, ticket printing, integration with photo capture, network connectivity.

6. Additional Features

• Calibration: Pre‑calibrated before shipment.

• Rugged build: Suitable for heavy industrial use.

• Connectivity: Often supports RS‑232, RS‑485 interfaces, and printer options.

  Summary Table

  Feature	Typical Specification
  Capacity	60 tons (60,000 kg)
  Accuracy Division	~10–20 kg
  Platform Size	Width ~3 m; Length 9–18 m
  Construction	Heavy steel beams with checkered/smooth plates
  Load Cells	IP68/IP69K sealed stainless-steel, overload rated
  Indicator/Display	Analog dial or LED/LCD; optional printing & data features
  Advantages	Space-saving, durable, flush design, protected components
